YEV09T20 20A DC-DC POL Converter
4.5V to 13.8V Input ? 0.59V to 5.1V Output
Data Sheet
100
95
90
85
Vin = 6.5V
Vin = 12V
Vin = 13.8V
0
5
10
15
20
Output Current, A
Figure 5. Efficiency vs. Load. Vout=5.0V
Figure 7. Typical Start-Up Using Remote On/Off
(Vo = 3.3 Vdc, Io=20A). Ch1 – Vout, Ch2 – ON/OFF,
5.2
Turn-On Characteristics
Ch3 - Iout
Figure 6. Typical Start-Up Using Remote On/Off
(Vo = 0.6Vdc, Io=20A). Ch1 – Vout, Ch2 – ON/OFF,
Ch3 - Iout
Figure 8. Typical Start-Up with application of Vin
(Vo = 0.6Vdc, Io = 20A). Ch1 – Vout, Ch3 – Iout,
Ch4 – Vin.
ZD-02093 Rev. 1.2, 18-Jun-10
www.power-one.com
Page 6 of 12
